Vibration tests with hydraulic power – our shaker test bench in action
Our hydraulic shaker is the ideal solution for demanding shock and vibration tests – whether in accordance to the railroad standard EN 61373 for an air conditioning unit with natural refrigerant CO2 from Merak Knorr-Bremse or based on individual customer specifications, as in the example shown.
Technical highlights:
- Tests in all three axes (X/Y/Z)
- Suitable for heavy test items up to 3 tons and large components with overhanging geometries
- Large test bench area:
🔸 Vertical table: 1400 × 1400 mm | 280 kN cylinder
🔸 Horizontal table: 1400 × 2200 mm | 160 kN cylinders
🔸 Expandable with fixture frame to up to 4 × 2 m - Frequency range from 1 Hz
- Shock tests up to 30 g
The combination of high load capacity, flexible installation position and adaptable test profiles turns the Shaker into the ideal platform for railroad technology – and far beyond.
